1/4”-1/2” Point of Use Pressure Regulators

Material: Body: SS316L / SS316L VAR
Diaphragm: SS316L / Hastelloy C-22
Seat: PCTFE / Vespel / Teflon

Typical Application
· For Hook-up system
· For special gas system
· For research labs
Features
· High cycle life
· Corrosion resistant
· Low & High Capability
· Designed for safety
· Low internal volumes
Specification
· Maximum Inlet Pressure: up to 4000 psi
· Outlet Pressure: 0~500 psi
· Operating temperature: -40oF to 500 oF
· Helium Leak Test (In board): 1x10-9 scc/sec
· Flow Range: 0-40 SLPM
· Porting: 2P~6P
· Inner surface: EP (10 Ra / 5 Ra); BA (Oil Free)
