Material: Body: SS316L
Bellows: SS316L
Seat: PCTFETypical Application
· Bulk gas distribution system
· Hook up system
· Vacuum piping system
· Centralized distribution system for solvents
· Nuclear R & D centers
Features
· High Flow Capacity
· High cycle life
· Straight-trough flow design
· Full bore
· 316L Bellows
Specification
· Pressure Rating: Vacuum to 10 bar
· Operating temperature: -10oC to 80 oC
· Helium Leak Test (In board): 1x10-9 scc/sec
· Inner surface: BA (20 Ra); EP (5 Ra)
· 6" Size available
|
